Cutting Stone Machine Marble Granite Bridge Saw Slab Cutter Machinery

CNC Tiles And Stone Machine Marble Granite Bridge Saw Slab Cutting Cutter Machinery.One stop shopping, sino Universal Machinery produces mining equipment, stone processing equipment, to provide customers with a complete stone processing plant design, provide complete after-sales service.

1. The bridge type infrared stone cutter is operated by computer so that it work automatically.

2. The parts and accessories of which are made of high quality steel.

3. The lifting moving driving by four lead pillars.

4. The electronic controling cabinet compries.The machine adopt PLC controlling system,variable-frequency drive(VFD) which can provide fine speed regulation,infrared checking and calibration instrument,touching operating system.

Inquiry Now
Category: Tags: , ,

CNC Tiles And Stone Machine Marble Granite Bridge Saw Slab Cutting Cutter Machinery.One stop shopping, sino Universal Machinery produces mining equipment, stone processing equipment, to provide customers with a complete stone processing plant design, provide complete after-sales service.

1. The bridge type infrared stone cutter is operated by computer so that it work automatically.

2. The parts and accessories of which are made of high quality steel.

3. The lifting moving driving by four lead pillars.

4. The electronic controling cabinet compries.The machine adopt PLC controlling system,variable-frequency drive(VFD) which can provide fine speed regulation,infrared checking and calibration instrument,touching operating system.

5. The computer automatic control ensures the accuracy of cutting;So,the machine endowed with high steadiness,effective and simplein operating characters.

6. Long working life, very durable.

7. Small noise, working well.

8. Better slab quantity and precision.

9. Large capacity, save energy and cost.

10. Equipped with Schneider frequency transducer and OMROM PLC, programmable and fully automatic.

Technical parameters

Model DTQ-450 DTQ-600 DTQ-700 DTQ-800
Max. cutting size 3200*2000*100mm 3200*2000*175mm 3200*2000*225mm 3200*2000*275mm
Diameter of blade Φ400-Φ450mm Φ400-Φ600mm Φ400-Φ700mm Φ400-Φ800mm
Size of worktable 3200*2000mm 3200*2000mm 3200*2000mm 3200*2000mm
Vertical turning angle of worktable 0-85° 0-85° 0-85° 0-85°
Rotation angle of worktable 0-90/0-360° 0-90/0-360° 0-90/0-360° 0-90/0-360°
Main motor power 15KW 18.5KW 18.5KW 18.5KW
Water consumption 3.5m³ /h 3.5m³ /h 3.5m³ /h 3.5m³ /h
Overall dimension 6000*4800*2600mm 6000*4800*2800mm 6000*4800*3150mm 6000*4800*3300mm
Total weight 8674KG 9161KG 10151KG 10650KG
